KF065R186J0100︱KF65

PRODUCT DESCRIPTION:

This is a 1.86 to 1.0 ratio agricultural gearbox, which is mainly used for Rotary Tiller. This rotary tiller gearbox uses cast iron housing,alloy steel carburized bevel gear and drive shaft.Gearbox bevel gears are driven at right angles.The gearbox has an input horsepower of 65HP, an input speed of 540rpm and an output torque of 1577Nm.

KAIFU can offer all kinds of rotary tiller gearboxes from 23HP to 100HP.

MODEL SPECS

Input Power             65 HP          47.8 KW

Input Speed             540 R.P.M

Output Torque         1577 NM

Ratio                         1.86:1

Weight                     62 KG

Gear Parameter       Z₁=15   Z₂=28   m=6.4

APPLY TO: ROTARY TILLERS
